1
Skid
MOC
SS
No.
Make
HI-TECH
Capacity
MODEL RO 600 Ltr.
Type
Rectangle
2
Feed Pump
Self Priming
Crompton / Kilosker
900 LPH
Pressure
3.5 KG/ CM2
Power Consumption
1 HP
3
Dual media Filter
Vertical
Diameter
12 Inch
Height
48 Inch
FRP
Type of Operation
auto
Back wash Time
15-20 minutes
Size of multi port valve
1 ”
4
Anti Scaling dosing system
Pump
1 Set
Aqua Italy / E-Dose / Hi-tech
Quantity
Electronic Diaphragm Type
0 to 4 LHP
Quantity of Tank
1 Nos.
Capacity of Tank
100 Liters
MOC of Tank
HDPE.
5
Cartridge Filter Housing
Flow rate
1 M3/hr.
Length of Housing
20”
Dia. Of Housing
4”
No. of Cartridge Housing
2 Nos.
6
Micron Cartridge Filter
PP
Length of Cartridge
Dia. Of cartridge
No. of Cartridge
Rating
5 Micron
“Purtrex”, Osmonics, USA.
7
Pressure Pump
Vertical centrifugal multi stage
CNP
Power consumption
2 HP
Flow
1 M3
10-12 Kg/CM2
8
Pressure Tube
Item
RO module consisting of membrane Housing With RO membrane mounted on skid.
SS 316
Dia.
Length
82”
Qty.
9
Membrane
TFC POLYAMIDE
Size
4” dia. x 40” BW 30-40X40
Flimtech(Dow)/CSM/ Hydranautics /Hi-Tech/Toray
0.0001 Micron.
10
CIP SYSTEM
Pump inlet cock
2 NOS
Pump out let cock
Final water out let cock
1 NOS
Tank
50 LTR
Filter housing with filter
1 SET
A
Digital Conductivity OR TDS Meter
Maximum Temperature
40 Degree Centigrade
Location
RO Permeate.
B
Flow Indicators
3 Nos.
Float Type Panel Mounted.
Maximum Op. Temp.
40 Degree Centigrade.
Measuring Points
RO Module Feed ,Product ,Waste Flow
C
Pressure Gauges
5 Nos.
Range
0-4 & 0-35 Kg / Cm2.
1) After Feed Pump.
2) After Sand Filter.
3) After Carbon Filter.
4) After Micron Filter.
5) After High Pressure Pump.
D
High Pressure Switch And Low Pressure Switch
1+1 Nos.
Before & After High Pressure Pump.
E
Pressure Control Valve
Reject Water Line
Nos.
Spring System USA.
F
Auto Flushing switch with Solenoid Valve.
G
Electronic Control Panel With A meter, Voltmeter, indicators, On off Switch
CPVC pipe line from Feed Pump to Inlet of High Pressure Pump.
SS pipe line from outlet of High Pressure pump to final water end point of system.
SS 304 box pipe frame.
